2800mm Web Tension Control System Alignment Balancing Roller 15mm Direction

Balancing Roller Web Tension Control System For Corrugated Cardboard Line

Product Parameter:

Features:

1, Automatically adjust the force balance of the base paper, and the direction of the paper force can be finely moved by 15mm.

2, Using high-precision grinding worm gear structure, precise and flexible movement to ensure stable execution.

3, Make sure the tension of the paper is uniform and avoid the warpage of the cardboard after molding due to the uneven tension.

4,Tension Sensor can be installed to realize automatic detection and adjustment of tension.

Importance of Balance Roller:

Before the paper enters the critical processing equipment (single-side machine or gluer) and after passing through equipment that affects the tension of the paper web (such as a preheater or pretreatment drum), the most effective way to ensure consistent tension is to measure the actual paper Width tension. The actual tension measured should be compared with the preset number, and then adjusted according to actual needs. The balance roller is to achieve this automatic tension adjustment function to ensure uniform tension of the paper and avoid warping of the cardboard after forming due to uneven tension.
